eCTH
Can To Hbridge

eCTH (ESTE Can To Hbridge) is a device capable of controlling via CAN J1939 network up to 6 DC actuators (e.g. Brush motor) in forward or reverse directions. Multiple eCTH modules can be connected on the same CAN Nertwork to increase the number of outputs, up to 16 eCTH, capable of controlling up to 96 DC actuators. Configuring a multi-module system does not require specific programming for each device, as ID assignment is based on the electrical connection.

Connessione multi-dispositivo

Use Cases

  • DC Motor Control
  • Solenoid Valve Control
  • Relay Control

Operating Environment

  • Agriculture
  • Earth-Moving Machines
  • Construction Machinery
  • Forklifts
  • Industrial

Technical Specifications

Power Supply: 8 – 32 VDC
Maximum Supply Current: 10A
Dimensions: 120 mm x 70 mm x 35 mm – Without connector
Weight: 250g
IP Rating: IP67
Temperature Range: -40 °C to 85 °C
Certifications: ISO 14982, EN 61000-2, EN 61000-3
Communication Interfaces: 1 x CAN
Outputs: 6 x HBridge (1A continuous, 1.5A for 30s, 4A peak)
